It's 4 AM, this is driving me crazy-sorry for the novel:
Have you checked to make sure your fuel rail is getting the pressure it needs or do you really think it's something electrical? You could take the pass side fender lining out and remove the filter and then turn the key and see or make sure fuel is getting that far at least.
As for the diagrams, someone else on here might have more info on that.
__________________
I do think it is electrical since I can get fuel when depressing the schrader valve-plus, for the most part, it will start and run-and when it does run, it runs well which I would think eliminates the fuel pump.
If it cranks, your starter and solenoid are good. Power to the ignition and stuff comes from the engine compartment Power Distribution (fuse box).
I wasn't clear - did you REPLACE the harness/connector for the crank sensor?
Check for spark. No spark is caused by no crank sensor signal.
Have you looked at the cam sensor?[/I]
I did replace the crank sensor and the harness-I did not check the cam sensor though, that is behind the power steering res, correct? Would that cause intermittent no-start?
It should still turn over with no cam sensor input, right? Mine ran (albeit not that well) with what ended up being a rusted-out connector at the cam sensor.
With either a bum crank sensor or cam sensor, it will crank but not start.
That's the thing, it does start-most of the time, but I will say that the most common thread is that it seems like, when it sits for hours, it'll start, you can drive it 30 miles with no issues-shut it off, and immediatly restart it with no problems-but sometimes if it sits for a few minutes, it won't start until time transpires (30 minutes to many hours, it seems). I doesn't always do that either-it is completely random.
I am wondering if maybe it hasa leaking injector. I had a 97 Cobra that would decide not to start at the weirdest times. Checked everything and replaced many sensors. Turned out three injectors were sticking open and bleading off pressure with the car off. So if it sat for more then 10 minutes and under 3 hours then it would not restart till the fuel evaped some.
Also you could have a dieing fuel pump.
Barring all that then you have a broken wire going into the computer or coils.
Have you checked fuel pressure and spark?
I thought of this last time I worked on it-I held the pedal to the floor, and it made no difference-tried that more than once. I am going to change the fuel filter tomorrow when I get it back, and I wondered too about the fuel pump, but if it craps out while running and getting 'hot', wouldn't that manifest itself while running, I mean you can drive this thing for 30 minutes and there are no issues at all. It is not low on fuel (over 1/2 a tank) so the fuel pump is covered with fuel-cools it too, correct?
I am going to drop the panel and look at the harness for the ECM, for whatever good that'll do...I am going to look at the cam sensor, probably just replace it. I hate just throwing parts at it, but it does have 170,000 miles on it, so I guess all kinds of items could use refreshing.
__________________
That would be easily diagnosed by holding the accelerator to the floor while cranking. If it has flooded due to leaky injectors, the injectors will be shut off and it will crank and clear the fuel from the cylinders. After a few seconds of cranking, release the throttle and try to start as normal. If it was flooded it will either start or try to start with the accelerator floored or it will start normally after clearing the flooded condition.
__________________
Thanks for the input, especially the cam sensor-I just got off the phone with him and he said he doesn't think he EVER changed the fuel filter...he's owned this since NEW! I am going to check the harness that goes into the coils also, although I would think this has to be more of a crank/cam sensor problem. thanks for all the ideas, I'll get back with findings.
