Intermittent overheating issue- totally confused

DBillet75

LVC Member
Joined
Oct 28, 2021
Messages
16
Reaction score
3
Location
Pa
2000 lincoln ls 6 cyl... I have had problems with my car overheating intermittently..replaced most of the cooling system parts, did proper bleed procedure, so I'm pretty sure it isn't air locked... it will start to overheat , but if I shut the car off and start it again the temp stays fine.. is there a fan relay or switch I'm missing that might be going bad? Any help or suggestions are greatly appreciated !


AmsterDutch

Dedicated LVC Member
Joined
Jul 9, 2017
Messages
2,355
Reaction score
451
Location
Midwest
2000 lincoln ls 6 cyl... I have had problems with my car overheating intermittently..replaced most of the cooling system parts, did proper bleed procedure, so I'm pretty sure it isn't air locked... it will start to overheat , but if I shut the car off and start it again the temp stays fine.. is there a fan relay or switch I'm missing that might be going bad? Any help or suggestions are greatly appreciated !
What bleeding procedure did you use? What coolant parts didn't you replace?


DBillet75

LVC Member
Joined
Oct 28, 2021
Messages
16
Reaction score
3
Location
Pa
I followed the bleed procedure on this forum with the bleeder on the crossover pipe and the one by the degas bottle .... replaced upper rad hose and crossover .. thermostat and housing.. t connector, degas bottle... pressure tested the system and everything seems ok on that end.. its just weird that I can shut the car off turn it right back on and it's fine which makes me think it's something else


AmsterDutch

Dedicated LVC Member
Joined
Jul 9, 2017
Messages
2,355
Reaction score
451
Location
Midwest
I followed the bleed procedure on this forum with the bleeder on the crossover pipe and the one by the degas bottle .... replaced upper rad hose and crossover .. thermostat and housing.. t connector, degas bottle... pressure tested the system and everything seems ok on that end.. its just weird that I can shut the car off turn it right back on and it's fine which makes me think it's something else
I can't remember does the V6 have a DCCV DUAL CLIMATE CONTROL VALVE? Is your hydraulic fan speeding up coming on when you turn on the AC?


DBillet75

LVC Member
Joined
Oct 28, 2021
Messages
16
Reaction score
3
Location
Pa
It does have dual climate control..but I don't believe the fan is speeding up when I turn on the ac


04_Sport_LS

Dedicated LVC Member
Joined
Jun 12, 2012
Messages
5,305
Reaction score
939
Location
Somewhere around Lake Erie
You still have air in the system... and need to bleed it some more.

The air will form in pockets in the block, or other parts of the cooling system and restrict flow.

When you shut the engine off... the air pockets "settle out"... "burping" (semi bleeding) itself.


04_Sport_LS

Dedicated LVC Member
Joined
Jun 12, 2012
Messages
5,305
Reaction score
939
Location
Somewhere around Lake Erie
.



AmsterDutch

Dedicated LVC Member
Joined
Jul 9, 2017
Messages
2,355
Reaction score
451
Location
Midwest
Any ideas?
Yes 04' Sport is correct...first make sure you don't have air in the cooling system ...if you're sure you have all the air out then the next thing I want to know is your AC blowing cold?


DBillet75

LVC Member
Joined
Oct 28, 2021
Messages
16
Reaction score
3
Location
Pa
It blows cold till the temp gets too high.. but I haven't had the chance to get back to it... this weekend I'll be back at it.. bleed system and see if I can get more air out of it. I'll keep you updated. Thanks again for the replies gentlemen!


heyjewel

Dedicated LVC Member
Joined
Oct 5, 2015
Messages
515
Reaction score
48
Location
auburn
2000 lincoln ls 6 cyl... I have had problems with my car overheating intermittently..replaced most of the cooling system parts, did proper bleed procedure, so I'm pretty sure it isn't air locked... it will start to overheat , but if I shut the car off and start it again the temp stays fine.. is there a fan relay or switch I'm missing that might be going bad? Any help or suggestions are greatly appreciated !
I had a similar issue with my 2001 V6. There is a little thing that controls the cooling fan and it wasnt speeding my fan up enough. Coolant was bubbling up in the reservoir and car would overheat. I cant recall what the thing is called and I will say it was very hard to get. A low mileage V6 at a boneyard may be worth a visit. If I can find a diagram or part call ut I will post it. Good luck.


heyjewel

Dedicated LVC Member
Joined
Oct 5, 2015
Messages
515
Reaction score
48
Location
auburn
I had a similar issue with my 2001 V6. There is a little thing that controls the cooling fan and it wasnt speeding my fan up enough. Coolant was bubbling up in the reservoir and car would overheat. I cant recall what the thing is called and I will say it was very hard to get. A low mileage V6 at a boneyard may be worth a visit. If I can find a diagram or part call ut I will post it. Good luck.
It's called the hydraulic actuator I think. This thread will tell you a bit about all the issues I had until milehighmikey jumped in with into about that actuator. The thing cost me over $200 but it did fix all my problems. mhm recommended against a boneyard actuator.


FL_lincoln

New LVC Member
Joined
Aug 5, 2022
Messages
4
Reaction score
0
Location
Florida
I can't remember does the V6 have a DCCV DUAL CLIMATE CONTROL VALVE? Is your hydraulic fan speeding up coming on when you turn on the AC?
I'm having overheating issues with my 2002 Lincoln LS 3.0L and reading threads here to troubleshoot. How do I know if the hydraulic fan is speeding up? I've found the fan difficult to troubleshoot because it's so difficult to see.


FL_lincoln

New LVC Member
Joined
Aug 5, 2022
Messages
4
Reaction score
0
Location
Florida
You still have air in the system... and need to bleed it some more.

The air will form in pockets in the block, or other parts of the cooling system and restrict flow.

When you shut the engine off... the air pockets "settle out"... "burping" (semi bleeding) itself.
Is bleeding the engine several times a reliable technique for addressing overheating? We've had the pressure cap, thermostat, and water pump replaced and it's still overheating. No loss of coolant that I can see. Another question--is it possible that the system could pressure test fine but still have a leak that allows air to re-enter the system?


heyjewel

Dedicated LVC Member
Joined
Oct 5, 2015
Messages
515
Reaction score
48
Location
auburn
Is bleeding the engine several times a reliable technique for addressing overheating? We've had the pressure cap, thermostat, and water pump replaced and it's still overheating. No loss of coolant that I can see. Another question--is it possible that the system could pressure test fine but still have a leak that allows air to re-enter the system?
I think so. Is the coolant boiling / bubbling in the degas bottle? That is what mine was doing until I replaced that actuator and then all was well.


AmsterDutch

Dedicated LVC Member
Joined
Jul 9, 2017
Messages
2,355
Reaction score
451
Location
Midwest
I'm having overheating issues with my 2002 Lincoln LS 3.0L and reading threads here to troubleshoot. How do I know if the hydraulic fan is speeding up? I've found the fan difficult to troubleshoot because it's so difficult to see.
If the hydraulic fan speeds up when the AC is on you'll know it...its way louder and faster ...have someone watch the fan when you turn on your AC


DBillet75

LVC Member
Joined
Oct 28, 2021
Messages
16
Reaction score
3
Location
Pa
So I spent the day so far bleeding , driving a few miles, bleeding, and such, and I'm 99% positive I got all of the air our of the system...ac blows hot when it gets hot , fan doesn't change speed.. so I'm guessing the hydraulic actuator is shot..looks like a pain to.get to .lol


04_Sport_LS

Dedicated LVC Member
Joined
Jun 12, 2012
Messages
5,305
Reaction score
939
Location
Somewhere around Lake Erie
We've had the pressure cap, thermostat, and water pump replaced and it's still overheating. No loss of coolant
There are a bunch of other (plastic) parts (that if bad) will cause overheating by allowing air to get into the cooling system.

It's been repeated probably 100 times on this forum.

Replace all cooling system parts at the same time... with OEM (factory) parts... and you will not have to worry about it again for roughly 7 years.

Now if the issue is the hydraulic fan is not working properly... that's a different story. The hydraulic actuator and/or pump may be bad.

That opens up a different can of worms.
