help with my stock amp

Lincoln LS

  1. freshkid87

    freshkid87 LVC Member

    Messages:
    48
    Likes Received:
    0
    Joined:
    Mar 4, 2014

    All the other speakers work sides rear 2


  2. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    Yeah - me too - if you find a solution, post it up. I've been hunting for weeks.

  3. 2002_lincolnLS

    2002_lincolnLS Custom User Title

    Messages:
    3,682
    Likes Received:
    29
    Joined:
    Sep 17, 2009
    Location:
    canton
    amp probably died...

  4. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    wish it were that simple - tried another working (stock lincoln) amp - no dice. My current theory is that the remote turn on signal isn't coming from the stock head unit...

  5. joegr

    joegr Dedicated LVC Member

    Messages:
    19,665
    Likes Received:
    1,443
    Joined:
    Dec 10, 2005
    Location:
    Gulfport
    Well, that's easy enough to measure and confirm or rule out.

    How about the subs themselves? They are fairly well known to fail. Note that with the factory amp, if one sub fails (or is unplugged), it will barely drive the remaining sub.

  6. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    yeah - it seems as though I have continuity in the wire between the dash and trunk for remote turn on - that's a tough reach with a meter! but it did show continuity most of the time in my rigged up test! There's no real way to test the output of the head unit AFAIK other than the system self test - no codes thrown.

    both subs thump with a 1.5 volt cell, so they "simple tested" ok - one of the connectors is a little janky (wire tied on - the PO had some sort of aftermarket system in) - will check the wiring on that connector again.

    Thanks for the tip, Joegr

  7. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    honestly, after testing that one connector tonight if that fails, I'm probably just going to replace the head, maybe the speakers and add a powered sub and be done with it....stereos are cheap enough these days.

  8. joegr

    joegr Dedicated LVC Member

    Messages:
    19,665
    Likes Received:
    1,443
    Joined:
    Dec 10, 2005
    Location:
    Gulfport
    You are over complicating it.
    Turn the radio on.
    Measure the voltage between the amp turn-on signal (at the sub amp) and ground. If I remember correctly, it will be a little over 7 volts. If it's less than 6 volts, it's the problem.

  9. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    it's zero volts back at the sub amp harness on that pin, joe....that's absolutely the problem - the question is why? - lack of continuity in the wire? seems not, or something in the head unit...seems so.

    If I jump the constant power to the turn on, I get a thump....that's good, but it wants 7, not 12+ volts....could put a resistor in, but that's gonna leave the amp on all the time, so not a great workaround.

    It's as if there's a setting in the head unit that is switched to 'sub amp off'....

  10. joegr

    joegr Dedicated LVC Member

    Messages:
    19,665
    Likes Received:
    1,443
    Joined:
    Dec 10, 2005
    Location:
    Gulfport
    This is the factory head unit that we are talking about?
    Do you have center console speakers? If so, do they work? If "yes" to both, then you could route the turn-on signal to the center amp to the sub amp as well.

    If you jump constant power (via a resistor) to the turn-on pin on the amp, you will run the battery down. You could jump switched power (one of the accessory circuits) via a resistor to the turn-on pin.

  11. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    Yes, and yes - that's an idea...easy to try too...

  12. freshkid87

    freshkid87 LVC Member

    Messages:
    48
    Likes Received:
    0
    Joined:
    Mar 4, 2014
    Any solution yet

  13. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    been busy - haven't tried anything - how about you?

  14. FDR

    FDR Dedicated LVC Member

    Messages:
    1,934
    Likes Received:
    127
    Joined:
    Jan 20, 2014
    Location:
    Central NJ
    I'm pretty sure I'm using a 12v>5v converter for the turn on signal (from an aftermarket radio) and the amp definitely turns on

  15. freshkid87

    freshkid87 LVC Member

    Messages:
    48
    Likes Received:
    0
    Joined:
    Mar 4, 2014
    naw ,, i miss my rear speakers in the back working, my car sounds like ass crack right now

  16. fudge12

    fudge12 Dedicated LVC Member

    Messages:
    693
    Likes Received:
    15
    Joined:
    Jun 30, 2012
    Location:
    Brooklyn
    How are the acoustics?

  17. freshkid87

    freshkid87 LVC Member

    Messages:
    48
    Likes Received:
    0
    Joined:
    Mar 4, 2014
    Work fine. Jus gonna get a sub and wire them to that it's 55 here In Iowa

  18. jammit

    jammit LVC Member

    Messages:
    32
    Likes Received:
    1
    Joined:
    Nov 10, 2014
    Location:
    Plainfield
    Ended up putting a new head unit in - connected up the 2 subwoofers with the Metra harness - the front ambient ones work just fine as they did before. Still nothing back at the harness under the rear deck other than 12v constant power. There has to be something disconnected or cut somewhere on this car -

    Gave up fiddling with it and put in a cheap Bazooka BTA850FH which worked out just fine - it's no powerhouse sub, but 100% perfectly adequate for my purposes. Took less than an hour to install, and sounds great.
